Threaded And Solder Ends Plain Brass Boiler Drain Valve For Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | Meibo |
| Model Number: | LT-19412 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 |
|---|---|
| Delivery Time: | 5-10 DAYS |
| Payment Terms: | T/T |
| Supply Ability: | 50000 Piece/Pieces per Month |
|
Detail Information |
|||
| Features: | Lead-Free | Media: | Water |
|---|---|---|---|
| Material: | Brass | Structure: | Control |
| Application: | Boiler Drain | Power: | Hydraulic |
| Product Name: | Boiler Drain Valve | Medium: | Water Oil Gas |
| Standard: | NPT BSP | Customized Support: | OEM, ODM |
| Inlet Thread Type: | NPT | Handle Type: | Round |
| Body Style: | Straight | Size: | 1/2 Inch |
| Connection Type: | Male NPT | Handle Material: | Plastic |
| Drain Type: | Full Port | Valve Type: | Quarter Turn |
| Outlet Thread Type: | Hose | Maximum Temperature: | 200°F |
| Maximum Pressure: | 125 Psi | ||
| High Light: | Solder Ends Boiler Drain Valve,Threaded brass boiler drain valve,Brass Boiler Drain Valve |
||
Product Description
Boiler Drain
Casting Body • Rising Stem
Pipe Threaded Comply With ANSI B16.18
Hose Threaded Comply With ASME B 1.20.7
Solder Ends Comply With ANSI B16.18 Note: Plain
| MATERIAL LIST | |
| PART | SPECIFICATION |
| Hand Screw | C37700 |
| Hand Wheel | Cast Iron With Painting |
| Nut | Brass ASTM B124 C37700 |
| O-ring | NBR |
| Stem | Brass ASTM B124 C37700 |
| Body | ASTM B124 C37700 |
| Disc | EPDM |
FAQ
1. Are you factory or trading company ?
YUHUAN MEIBO COPPER CO.,LTD. Is an export-oriented enterprise. Which is specialized in exporting a variety of valves, include ball valve, gate valve, ant-freezing valve, stop valve, check valve...Etc.
The factory YUHUAN MEIBO group include 3 professional valve production base, main valve production at the same time water heating accessories, all passed iso9001:2015 quality system certification, the total area is over 30000 square meters, annual turnover more than 30 million us dollar, we are dedicated in north american and europe market since the factory was founded in 1987, all products from us are sold abroad, 90% to north american and europe market.
We have an integrated quality guarantee system and after-sale services system. Advanced product equipment, perfect testing skills and quality assurance system make sure all products from us can pass the CSA and UPC test, multiple products have obtained CUPC, CSA and NSF certificates.
