SS 3/4 Brass Ball Valve Male And Female Threaded With Virgin Ptfe Seat And Blow Out Proof Stem
Product Details:
| Place of Origin: | China |
| Brand Name: | MB |
| Model Number: | LT-1045FM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 |
|---|---|
| Delivery Time: | 5-10 DAYS |
| Payment Terms: | T/T |
| Supply Ability: | 50000 Piece/Pieces per Month |
|
Detail Information |
|||
| Media: | Water,Gas,Oil | Application: | General |
|---|---|---|---|
| Medium: | Water, Oil | Standard: | ANSI |
| Processing Technic: | Sand Blast And Nickel Plate | Gasket: | FTFE |
| Connection: | Thread | Flow Rate: | Full Port |
| Temperature Of Media: | Medium Temperature | Technics: | CNC |
| Sureface: | Nickel | Valve Type: | Ball Valve |
| Theread: | F/f Iso228/1 | Handle Finish: | Chrome Plated |
| Technology: | Forged | Range: | Gas Pipe Connection |
| Manufacturer: | XYZ Company | Lead Time: | 21 Days |
| High Light: | Ptfe Seat 3/ 4 brass ball valve threaded,SS 3/ 4 brass ball valve threaded,Ptfe Seat 3/ 4 inch ball valve brass |
||
Product Description
SS brass threaded ball valve Forged Brass Ball Valve with Virgin Ptfe Seat and Blow-out Proof Stem
Brass Valve
1. Construction: Two Piece Body, Forged Brass.Virgin Ptfe Seat, Blow-out Proof StemAl Handle.
2.Working Pressure: PN40
3. Applicable Medium: Water, Oil, Gas, Non-causticitySaturated Steam
4.Working Temperature:-20℃-180℃
5.Parallel Thread Conform To lSO-228-1: 2000
| NO. | COMPONENT | MATERIAL |
| 1 | Body | Brass |
| 2 | Bonnet | Brass |
| 3 | Stem | Brass |
| 4 | Ball | Brass |
| 5 | Seat ring | PTFE |
| 6 | Handle | AL |
| 7 | Screw | steel |
| 8 | O-ring | NBR |
This brass ball valve is designed with a 3/4 inch size and features both male and female threaded connections. It is equipped with a Virgin Ptfe Seat, which ensures a reliable and tight seal, preventing any leakage. Additionally, the valve is built with a Blow out Proof Stem, providing extra safety and durability.
